C29N

C29N is a camera equipped with 0.7T of intelligent computing power and professional-grade DSM capabilities. It features a built-in face-centered exposure function, which can handle various complex lighting conditions, including slanting sunlight, reflective clothing, and light-absorbing clothing. The camera is equipped with a G-Sensor, supports A-pillar and dashboard mounting, and can automatically adjust the image to fit different installation positions. It is designed to capture clear images at distances of 50 – 100 cm from the driver ’ s face, meeting installation requirements across a wide range of vehicle models. Additionally, the camera utilizes industry-leading infrared flash frequency technology, which significantly reduces power consumption and extends the device's lifespan.

Product Features

• Supports local operation of DMS intelligent algorithm
• Supports face-centered exposure function
• Supports the strobe function of infrared lamp power adjustment
• Equipped with a built-in G-sensor for automatic horizontal and vertical image adjustment based on installation position
• Supports standard 3mm wide-angle lens, effectively solving the problem of driver out of frame
• Resolution: 1280 * 800 @ 30FPS
• Supports N9M 2.0 protocol
• Built-in audio capabilities
• Adjustable installation Angle (A-pillar): Vertical direction: 0~360 ° ; horizontal direction: 0~180°
• Typical application: A-pillar side mounting, windshield installation, and vertical table mounting

C29N datasheet.pdf
